1. The machine has high speed setup, it can embroidery several chain stitch flat designs at the same time and can realize the function of auto trimmer.

2. Cording devices attachment, can embroider cording designs; Boring device attachment ,can embroider boring designs; Sequin device attachment, can embroider sequin designs;Bead-Pipe device attachment, can embroider bead and pipe designs.

3. Use the latest DAHAO C16 embroidery machine electric control.

4. High speed chassis, double driver and leap motor setup realize the embroidery in high speed.

5. Using the upper motor transmission in the main shaft makes it more accurate.

6. Press foot can be adjusted, suitable for embroider on different thickness of the material.

7. High strength new structure of bridge chassis makes the machine more stable in doing the embroidery.

8. AC servo motor driver used in the panto-graph drive let the movement fast quiet and smooth.

9. High accurate liner guide system used in the panto -graph guide can reduce the fault, abrasion and noise, and survive for long time.

10. Stepper motor static shear line system and the new AC motor to cancel, coupled with electromagnet line clamping mechanism, make the cut line is more quiet and stable.

11. Auto oiling device enlongs the life of the machine and ensures accurate stitching. (choose)

Rating speed: 1000rpm

Main motor: AC servo motor 3 sets

Power: Three phase 380V/50HZ, Single phase 220V/50HZ

Sequin device size: φ3、φ5、φ7、φ9

Sequin rating speed: 700rpm

Sequin max speed: 800rpm

Bead-Pipe Embroider: Specifications for Φ 2.4-2.7, height H1.7-1.8

Bead-Pipe max speed: 700rpm

Take-up Seace: 90mm

Movements Area: 25mm

Air pressure: 3 Kpa

Long Life: 20 years assembly experience, professional technical guidance，extend machine life for 2-3 years.

High Quality: choose imported bobbin, top speed of 1200 per minute speed, speed stability, low noise.

Less Maintenance: high precision，less disconnection, effectively improve embroidering quality，increase profit.

Exquisite Technology: Provide comprehensive technical training for free,both at home and abroad set up offices and after-sales service center.

Precision Processing: selecte parts from domestic and international famous suppliers, quality from the source control, more delicate embroidery.
